45° Switch Life Tester IEC 60884-1 Figure 21 Plug Socket - Outlet Flexible Cable 90° Flexing Test Apparatus
Products Description
IEC 60884-1 Figure 21 Apparatus for Flexing Test of Plug Socket-outlet Flexible Cable
Product information:
The flexible cable flexibility test apparatus meets the requirements of IEC 60884-1 figure 21 clause 23.4, which is used to process the flexing test for the flexible cable of non-rewirable plugs and non-rewirable portable socket-outlets.
Equipment characteristics:
The test times (up to 999999) can be preset on this test apparatus, and the test can be carried on and the numbers of tests can be calculated automatically. When the test times reach to the preset value, the system will shut down automatically and give out completion signals. Once the test apparatus connects to external load cabinet, it can be used to process test with load.
Technical parameters:
Mechanical theory
Power Supply
AC220V, 50Hz or match the client's site local power supply
Test Stations
6, with 6 sets of clamps
Flexing Times
1-999999 (can be preset). With 6 independent counters corresponding to each station, and there is a general counter
Flexing Rate
10~60 rpm (can be adjustable)
Flexing Angles
Swivel angle on either side for 45°, 60°, 90°
Sample Connecting Wires
6 PCS
Weights
10N/20N*6(the weight as per UL requirements is 113g and 284g)
Breaking indication
Indicator display
Dimensions
L*W*H=870mm *610mm* 820mm
Conforms to standard
IEC884-1 Figure 21 and clause 23.4, IEC320-1, VDE0620
The crank block on the reduction gearbox is driven by the electric motor to do the reciprocating action.
