16 Channels Temperature Measurement and Recording Instrument 1000 ℃ Temperature Recorder
Products Description
16 Channels Temperature Measurement and Recording Instrument 1000 ℃ Temperature Recorder
Standards & Clauses:
IEC60335-1:2016 “Household and similar electrical appliances-Safety-Part1:General requirements” clause 11
Samples and Restrictions:
Household and similar electrical appliances such as microwave oven, refrigerator and etc.
Application:
It is used to measure the temperature rise of various electrician and electrical appliances during normal use.
Test Principle:
Monitoring the real-time temperature by composing a temperature measuring circuit through electronic components.
Structure:
Desktop type
Equipment dimensions: approx.: 320 × 300 × 150 (mm) W × H × D
Equipment weight: 5kg
Use Environment:
Power supply:AC220V±10%/50-60Hz or match client's local power supply
Working temperature 0-40 ° C, humidity 30%-90%
Technical Parameters:
±0.3% rdg+ 1℃
Resolution: 0.1℃
Measuring range:-50 ～1000 ℃
Collect and store temperature data and draw temperature curve
Channels
8 channels, 16 channels, 32 channels, optional or can be customized
Electrical Control Method
7-inch humanized touch interface operation, the temperature data and temperature rise curve can be displayed on the interface
Measurement Accuracy
Test Software Content
Standard Configuration
With RS232 serial port for serial communication with computer
Configure the micro printer to print multiple temperature data at regular intervals. The print measurement interval can be set by the user.
Configured according to the number of stations, 2 meters / strip of American imported K-type thermocouples. (temperature range -50 to 260 ° C, wire diameter 0.522 mm)
With USB storage function, there is a 8GU disk, test data can be stored in real time and exported through software
With temperature probe, it can be operated with power (within 250V) without damaging the instrument itself.
The upper and lower limit alarm functions are optional
